Climb technical steeps and rail descents with confidence and speed. This agile 29er is designed with a smooth and active suspension setup, a lightweight aluminum frame, and progressive trail geometry to help you up your game.
This super-versatile trail machine is built on a lightweight, stiff and super-strong ALUXX SL frameset that blends our latest Maestro suspension technology with progressive, trail-oriented geometry. To soak up every bump, from big rocks to small undulations, we gave it a trunnion-mount shock and an Advanced Forged Composite upper rocker arm. This combination produces 115mm of smooth, active rear-wheel travel that puts you in control. Upfront, it features a 130mm travel suspension fork, and the overall geometry has been tuned and developed to maximize its performance on rugged trails.
29er confidence and control
Larger 29-inch diameter wheels roll over rugged terrain with balance and stability, giving you the momentum to tackle technical climbs and the confidence to fly on fast, rugged singletrack descents.
Maestro rear suspension features a trunnion-mount shock with a longer stroke and smoother feel. With 115mm of full rear travel (and 130mm up front), it has an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.
The lightweight and durable ALUXX SL aluminum frameset feature fast trail-riding geometry including an aggressive 66.5-degree headtube angle and 74.5-degree seat tube angle, plus a 44mm fork offset. The result is agile and efficient climbing capabilities
|Sizes||S, M, L, XL|
|Frame||ALUXX SL-Grade Aluminum, 115mm Maestro suspension|
|Fork||Marzocchi Z2, 130mm, GRIP damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant|
|Shock||Fox Float DPS Performance, 165/42.5, custom tuned for Giant|
|Handlebar||Giant Contact TR35, 780x35mm, 20mm rise|
|Stem||Giant Contact SL 35|
|Seatpost||Giant Contact Switch dropper post with remote, 30.9|
|Rear Derailleur||Shimano Deore|
|Brake Levers||Shimano MT401|
|Cassette||Shimano Deore, 10x51|
|Crankset||Praxis Cadet Boost, 30t|
|Bottom Bracket||Praxis, press fit|
|Rims||Giant AM 29 tubeless ready sleeve-joint rim, 30mm inner width|
|Tires||[F] Maxxis Minion DHF 29x2.3, 3C, EXO, TR [R] Maxxis Aggressor 29x2.3, 3C, EXO, TR, tubeless|
|A||SEAT TUBE LENGTH (inch)||15||17||18.3||19.5|
|B||SEAT TUBE ANGLE||74.5°||74.5°||74.5°||74.5°|
|C||TOP TUBE LENGTH (inch)||23.3||24.1||24.9||25.7|
|D||HEAD TUBE LENGTH (inch)||3.7||4.3||4.3||4.7|
|E||HEAD TUBE ANGLE||66.5°||66.5°||66.5°||66.5°|
|F||FORK RAKE (inch)||1.7||1.7||1.7||1.7|
|I||CHAIN STAY LENGTH (inch)||17.1||17.1||17.1||17.1|
|J||BOTTOM BRACKET DROP (inch)||1.4||1.4||1.4||1.4|
|M||STAND OVER HEIGHT (inch)||27.9||29.1||30||30.9|
|N||HANDLEBAR WIDTH (inch)||30.7||30.7||30.7||30.7|
|O||STEM LENGTH (inch)||1.6||1.6||2||2.4|
|P||CRANK LENGTH (inch)||6.7||6.9||6.9||6.9|
