From parkways to paths and everything in between, this versatile bike can add some spice to your commute or fitness routine. With its flat handlebar, upright positioning and suspension fork, you’re free to ride different types of terrain with confidence and control.

With a rugged personality and a smooth riding style, ATX features the familiar flat handlebar look of a traditional mountain bike. It has a lightweight yet durable ALUXX aluminum frame and a suspension fork with 100mm of smooth travel to soak up bumps. The wheel diameter varies based on bike size, with 26-inch wheels on smaller frames and 27.5 on larger ones. This tailors the bike’s handling to a rider’s height. Integrated mounts make it easy to add racks or fenders to suit your riding adventures.

All-terrain versatility

With a mountain bike style flat handlebar, suspension fork and disc brakes, you can ride road or dirt with confidence.

Lightweight and durable

Frameset constructed with high-quality ALUXX aluminum.

Comfort and stability

Frame geometry puts the rider in a position that balances efficiency with stability on rough roads, paths or trails.

Specifications

Sizes	26: XXS,XS,S 27.5: S,M,L,XL
Colors	Vibrant Blue, Black
Frame	ALUXX-Grade Aluminum
Fork	SR Suntour M3030A, 100mm
Shock	N/A
Handlebar	Giant Sport
Stem	Giant Sport, alloy, 15-degree
Seatpost	Giant Sport, 30.9
Saddle	Giant custom
Pedals	platform
Shifters	EF413
Front Derailleur	Shimano Tourney
Rear Derailleur	Shimano Tourney
Brakes	MTB linear pull
Brake Levers	Shimano EF41
Cassette	Shimano MF-TZ500, 14x34
Chain	KMC Z7
Crankset	ProWheel forged, 24/34/42
Bottom Bracket	cartridge
Rims	Giant CH17 alloy
Hubs	alloy, sealed bearing
Spokes	stainless, 14g
Tires	Giant Quickcross, 27.5x2.2 / 26x2.2

Geometry

		S (27.5")	M (27.5")	L (27.5")	XL (27.5")
A	SEAT TUBE LENGTH (inch)	16.5	17.9	19.9	21.1
B	SEAT TUBE ANGLE	73.5°	73.0°	73.0°	73.0°
C	TOP TUBE LENGTH (inch)	22.6	23.2	24	24.8
D	HEAD TUBE LENGTH (inch)	3.7	4.3	5.7	6.7
E	HEAD TUBE ANGLE	68.0°	68.0°	68.0°	68.0°
F	FORK RAKE (inch)	1.7	1.7	1.7	1.7
G	TRAIL (inch)	3.6	3.6	3.6	3.6
H	WHEELBASE (inch)	42.5	43	43.9	44.7
I	CHAIN STAY LENGTH (inch)	17.1	17.1	17.1	17.1
J	BOTTOM BRACKET DROP (inch)	2	2	2	2
K	STACK (inch)	22.9	23.4	24.7	25.6
L	REACH (inch)	15.9	16.1	16.5	17
M	STAND OVER HEIGHT (inch)	28.4	29.4	31.1	32
N	HANDLEBAR WIDTH (inch)	26	26	27.6	27.6
O	STEM LENGTH (inch)	2.8	2.8	3.5	3.5
P	CRANK LENGTH (inch)	6.7	6.7	6.9	6.9
Q	WHEEL SIZE	27.5"	27.5"	27.5"	27.5"
