Reassembling Your New Bike
Congrats!
Congratulations on your purchase of a new bicycle! The freedom and joy that comes with cycling is truly unparalleled, and there are many incredible adventures just around the corner, but first let's get this baby built!
Your new bike arrives from Bicycle Warehouse with most of the hard work already taken care of to make it as easy as possible for you to get out and riding those roads and trails. It's easy for experienced wrenchers and beginners alike. Just follow these simple steps:
Assembly Time
Level 1 - "Never-Ever"
Never assembled a bike and working with tools isn't your forte'
Assembly Time 60-80 minutes
Level 2 - "I'm Handy"
Never assembled a bike yet you are pretty mechanically handy.
Assembly Time 40-50 minutes
Level 3 - "DIY Bike Mechanic"
Never fully assembled a bike but have done a little bike tuning
Assembly Time 30-40 minutes
Level 4 - "Certified"
You’re a skilled bicycle mechanic
Time yourself, I bet you can assemble this bike in less than 10 minutes
Tools Needed
- 4, 5mm Hex Allen Keys*
- 15mm Pedal Wrench or 6mm Allen *
- Bike Grease*
- Bicycle Tire Pump*
- #2 Phillips Head and Flathead Screwdriver *
- Box Cutter or Strong Scissors
Click on the logo below for brand-specific videos on how to get your bike rolling.
When it comes to riding hard and fast on challenging off-road terrain, there’s almost nothing this ambitious trail bike can’t do. From steep, technical climbs to rowdy descents, Trance gives you the perfect blend of quickness and control.
This is a trail bike that thrives in the most challenging conditions. The frameset is engineered with a lightweight yet super strong and stiff ALUXX SL aluminum frame. It has updated Maestro rear suspension featuring a trunnion-mount shock and Advanced Forged Composite rocker arm to soak up bumps small and large. You get 140mm of smooth, active rear travel that gives you the traction and control you need to be one with the trail. Frame geometry is designed around its 27.5 wheels, which deliver both quickness and control on rugged terrain. Up front, you have a 150mm suspension fork for even more confidence. Just pick your line, point it and go.
FEATURES
27.5 agility and control
27.5-inch wheels balance agility and control, giving you the ability to roll over rugged terrain, flick the bike at speed, change lines, and explode out of corners.
Progressive suspension
Updated Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 140mm of rear travel (and 150mm up front), it has an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.
Trail-tuned chassis
The lightweight, stiff and durable ALUXX SL aluminum frameset features updated geometry to give you confidence on technical trails. The result is agile and efficient climbing plus added control for trails ranging from chunky singletrack to flowy high-spee
Specifications
Sizes | S, M, L, XL |
---|---|
Colors | Matte Black/Gloss Black/Chrome |
Frame | ALUXX SL-Grade Aluminum, 140mm Maestro suspension |
Fork | RockShox 35 Gold, 150mm, Boost 15x110 QR, tapered, custom tuned for Giant |
Shock | Fox Float DPS Performance, 185/52.5, custom tuned for Giant |
Handlebar | Giant Connect Trail, 31.8 |
Stem | Giant Contact |
Seatpost | Giant Contact Switch dropper post with remote, 30.9 |
Saddle | Giant Romero |
Pedals | N/A |
Shifters | Shimano Deore |
Front Derailleur | N/A |
Rear Derailleur | Shimano Deore, Shadow+ |
Brakes | Tektro HDM735 hydraulic |
Brake Levers | Shimano MT401 |
Cassette | Shimano Deore, 12-speed, 10x51 |
Chain | Shimano |
Crankset | Praxis Cadet Boost, 30t |
Bottom Bracket | Praxis, press fit |
Rims | Giant AM 27.5 wheelset, alloy, 30mm inner |
Hubs | Shimano Boost [F] 15x110 [R] 12x148, sealed bearing |
Spokes | Sapim |
Tires | [F] Maxxis High Roller II, tubeless, 27.5x2.5, WT, 3C, EXO, TR [R] Maxxis High Roller II, tubeless, 27.5x2.4, 3C, EXO, TR |
Extras | Tubeless prepared |
Geometry
S | M | L | XL | ||
---|---|---|---|---|---|
SEAT TUBE LENGTH (inch) | 15 | 17 | 19 | 20 | |
SEAT TUBE ANGLE | 73.5° | 73.5° | 73.5° | 73.5° | |
TOP TUBE LENGTH (inch) | 22.8 | 24 | 24.8 | 25.8 | |
HEAD TUBE LENGTH (inch) | 3.9 | 4.1 | 5.1 | 5.7 | |
HEAD TUBE ANGLE | 67.0° | 67.0° | 67.0° | 67.0° | |
FORK RAKE (inch) | 1.7 | 1.7 | 1.7 | 1.7 | |
TRAIL (inch) | 4.1 | 4.1 | 4.1 | 4.1 | |
WHEELBASE (inch) | 44.4 | 45.7 | 46.6 | 47.6 | |
CHAIN STAY LENGTH (inch) | 17.1 | 17.1 | 17.1 | 17.1 | |
BOTTOM BRACKET DROP (inch) | 0.6 | 0.6 | 0.6 | 0.6 | |
STACK (inch) | 23.1 | 23.3 | 24.2 | 24.7 | |
REACH (inch) | 16 | 17.1 | 17.6 | 18.5 | |
STAND OVER HEIGHT (inch) | 27.6 | 28.5 | 30.2 | 31 | |
HANDLEBAR WIDTH (inch) | 30.7 | 30.7 | 30.7 | 30.7 | |
STEM LENGTH (inch) | 2 | 2 | 2 | 2.4 | |
CRANK LENGTH (inch) | 6.7 | 6.9 | 6.9 | 6.9 | |
WHEEL SIZE | 27.5" | 27.5" | 27.5" | 27.5" |
