The mountain bike experience starts here. With a redesigned frame that’s now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance. *on select models
Key Performance Factors
Modern MTB Design
Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models
Off-Road Control
New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.
Light and Durable
All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.
![ALUXX Aluminum Technology](http://bicyclewarehouse.com/cdn/shop/files/aluxxslr_500x.png?v=1715647704")
ALUXX Aluminum Technology
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
More Info| XS (27.5") | S (27.5") | S (29") | M (29") | L (29") | XL (29") | ||
|---|---|---|---|---|---|---|---|
| A | Seat Tube Length (inch) | 13.6 | 14.8 | 15 | 16.5 | 17.7 | 18.9 |
| A1 | Seat Post Insertion Depth (inch) | 12 | 13.3 | 13.4 | 7.9 | 9.3 | 11.5 |
| B | Seat Tube Angle | 74.0° | 74.0° | 74.5° | 74.5° | 74.5° | 74.5° |
| C | Top Tube Length (inch) | 21.3 | 22.1 | 22.9 | 23.8 | 24.8 | 25.7 |
| D | Head Tube Length (inch) | 3.5 | 3.5 | 3.7 | 4.1 | 4.9 | 5.5 |
| E | Head Tube Angle | 67.0° | 67.0° | 67.5° | 67.5° | 67.5° | 67.5° |
| F | Fork Rake (inch) | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 |
| G | Trail (inch) | 4.1 | 4.1 | 4.3 | 4.3 | 4.3 | 4.3 |
| H | Wheelbase (inch) | 42.7 | 43.5 | 44.8 | 45.8 | 46.9 | 47.9 |
| I | Chain Stay Length (inch) | 17.3 | 17.3 | 17.9 | 17.9 | 17.9 | 17.9 |
| J | Bottom Bracket Drop (inch) | 1.8 | 1.8 | 2.2 | 2.2 | 2.2 | 2.2 |
| K | Stack (inch) | 21.6 | 21.6 | 23.5 | 23.9 | 24.6 | 25.2 |
| L | Reach (inch) | 15.2 | 15.9 | 16.3 | 17.2 | 18 | 18.7 |
| M | Stand Over Height (inch) | 26.9 | 26.9 | 28.1 | 27.9 | 27.9 | 28 |
| N | Handlebar Width (inch) | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
| O | Stem Length (inch) | 1.6 | 2 | 2 | 2.4 | 2.8 | 3.1 |
| P | Crank Length (inch) | 6.5 | 6.5 | 6.7 | 6.7 | 6.7 | 6.9 |
| Q | Wheel Size | 27.5" | 27.5" | 29" | 29" | 29" | 29" |
