Chunky rock gardens, gnarly roots and steep, technical climbs. The all-new Trance X 29 is for those who consider the hardest section of trail their favorite part of the ride. With longer suspension travel and adjustable geometry, this aluminum trail slayer delivers hard-charging singletrack fun.

Engineered to help you ride faster and smoother on the toughest trails, this all-new 29er has a lightweight, strong and stiff aluminum chassis with 29er-specific geometry and a plush ride thanks to its advanced new suspension setup. Longer travel Maestro suspension delivers 135mm of active rear travel that pairs perfectly with a 150mm fork. The Advanced Forged Composite rocker arm has a flip-chip that allows you to adjust frame geometry and tailor the bike’s handling to your riding style and terrain. Choose steeper or slacker headtube/seattube angles and either a 30mm or 40mm bottom bracket drop to adjust the handling for your riding style and terrain. It’s all built around 29-inch wheels and lots of clearance (up to 2.5-inch tires) for maximum control on rugged trails.

29er confidence and control

29-inch wheels roll over rough terrain with balance and stability, giving you more momentum for technical climbs and the confidence to fly on fast, rugged singletrack descents. Added clearance for up to 2.5-inch tires.

Progressive suspension

New Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 135mm of full rear-wheel travel (and 150mm up front), it features a two-position adjustable Advanced Forged Composite flip-chip equipped upper rocker arm for increased stiffness and strength plus lower overall frame weight.

Adjustable frame geometry

Lightweight ALUXX-SL frameset features adjustable geometry that offers 66.2 or 65.5-degree headtube and 77.9 or 77.2-degree seattube angles, resulting in 30mm or 40mm bottom bracket drop options for aggressive trail configurations.

Specifications

Sizes	S, M, L, XL
Colors	Balsam Green/Black/Chrome
Frame	ALUXX SL-Grade Aluminum front and rear triangles, 135mm Maestro suspension, flip chip
Fork	Fox 36 Float Rhythm, 150mm, GRIP damper, Boost 15x110 QR, 44mm offset, custom tuned for Giant
Shock	Fox Float DPS Performance, 185/55, custom tuned for Giant
Handlebar	Giant Contact TR35, 780x35mm, 20mm rise
Stem	Giant Contact SL 35
Seatpost	Giant Contact Switch dropper with remote, 30.9
Saddle	Giant Romero
Pedals	platform
Shifters	Shimano SLX
Front Derailleur	N/A
Rear Derailleur	Shimano SLX
Brakes	Shimano MT520
Brake Levers	Shimano MT501
Cassette	Shimano SLX, 10x51
Chain	KMC X-12
Crankset	Shimano MT510, 30t
Bottom Bracket	Shimano, press fit
Rims	Giant AM 29, alloy
Hubs	Shimano, sealed bearing
Spokes	Sapim
Tires	[F] Maxxis Minion DHF 29x2.5, 3C, EXO, TR [R] Maxxis Dissector 29x2.4, 3C, EXO, TR, tubeless
Extras	tubeless prepared

Geometry

	S	M	L	XL
	LOW \| HIGH	LOW \| HIGH	LOW \| HIGH	LOW \| HIGH
SEAT TUBE LENGTH (inch)	16.9	16.9	18.3	19.5
SEAT TUBE ANGLE	77.2° \| 77.9°	77.2° \| 77.9°	77.2° \| 77.9°	77.2° \| 77.9°
TOP TUBE LENGTH (inch)	22.3 \| 22.2	23.5 \| 23.4	24.8 \| 24.7	25.8 \| 25.7
HEAD TUBE LENGTH (inch)	3.7	3.9	4.3	4.7
HEAD TUBE ANGLE	65.5° \| 66.2°	65.5° \| 66.2°	65.5° \| 66.2°	65.5° \| 66.2°
FORK RAKE (inch)	1.7	1.7	1.7	1.7
TRAIL (inch)	4.9 \| 4.7	4.9 \| 4.7	4.9 \| 4.7	4.9 \| 4.7
WHEELBASE (inch)	46.2 \| 46.1	47.4 \| 47.4	48.8 \| 48.7	49.9 \| 49.8
CHAIN STAY LENGTH (inch)	17.2 \| 17.1	17.2 \| 17.1	17.2 \| 17.1	17.2 \| 17.1
BOTTOM BRACKET DROP (inch)	1.6 \| 1.2	1.6 \| 1.2	1.6 \| 1.2	1.6 \| 1.2
STACK (inch)	24.3 \| 24.1	24.4 \| 24.2	24.8 \| 24.6	25.2 \| 25
REACH (inch)	16.8 \| 17.1	18 \| 18.3	19.1 \| 19.4	20.1 \| 20.4
STAND OVER HEIGHT (inch)	28.9 \| 29.3	28.7 \| 29.1	29.7 \| 30	30.6 \| 30.9
HANDLEBAR WIDTH (inch)	31.5	31.5	31.5	31.5
STEM LENGTH (inch)	1.6	1.6	2	2
CRANK LENGTH (inch)	6.5	6.7	6.7	6.7
WHEEL SIZE	29"	29"	29"	29"
