Reassembling Your New Bike
Congrats!
Congratulations on your purchase of a new bicycle! The freedom and joy that comes with cycling is truly unparalleled, and there are many incredible adventures just around the corner, but first let's get this baby built!
Your new bike arrives from Bicycle Warehouse with most of the hard work already taken care of to make it as easy as possible for you to get out and riding those roads and trails. It's easy for experienced wrenchers and beginners alike. Just follow these simple steps:
Assembly Time
Level 1 - "Never-Ever"
Never assembled a bike and working with tools isn't your forte'
Assembly Time 60-80 minutes
Level 2 - "I'm Handy"
Never assembled a bike yet you are pretty mechanically handy.
Assembly Time 40-50 minutes
Level 3 - "DIY Bike Mechanic"
Never fully assembled a bike but have done a little bike tuning
Assembly Time 30-40 minutes
Level 4 - "Certified"
You’re a skilled bicycle mechanic
Time yourself, I bet you can assemble this bike in less than 10 minutes
Tools Needed
- 4, 5mm Hex Allen Keys*
- 15mm Pedal Wrench or 6mm Allen *
- Bike Grease*
- Bicycle Tire Pump*
- #2 Phillips Head and Flathead Screwdriver *
- Box Cutter or Strong Scissors
Click on the logo below for brand-specific videos on how to get your bike rolling.
Introducing the all-new Specialized Roll 3.0 Fitness Road Bike – your ticket to a fitness journey that's as exhilarating as a roller coaster ride! They say starting an exercise routine is like taking that first step into the unknown, but hey, who doesn't love a good adventure?
Get ready to redefine your exercise game with the Roll 3.0. Crafted from the lightweight alloy frame that's practically as light as a feather (well, almost!), this bike boasts eight speeds of "go fast or go home" gearing. Those stable and wide 650b tires are like the comfy couch of the biking world, ensuring you cruise along smoothly no matter where your fitness escapade takes you.
The Roll comes with hydraulic disc brakes that could stop a meteor (okay, maybe not a meteor, but you get the idea). So whether you're tackling hills, racing against the wind, or simply enjoying a leisurely ride, you'll have the power to stop on a dime.
In a world where fitness meets style, the Roll 3.0 is your ultimate wingman. Grab the Roll 3.0 and roll your way to a fitter, faster, and fantastically FUN you!
Features:
- The Roll is made of our A1 Premium Aluminum, and it features our Ground Control Positioning that makes it easy to put a foot down when stopped. This Roll also comes ready with rack/fender mounts.
- Wide diameter, 650b x 2.3" Nimbus II Sport Reflect tires provide excellent traction, stability, and cushioning, which creates a safer, more reliable, and more comfortable ride on either paved or dirt roads. Plus, the reflective accents of the tire increase your visibility to motorists in low-light conditions.
- Equipped with a Body Geometry Comfort Gel saddle, you can expect a supreme level of comfort anywhere you ride. It is ergonomically designed and scientifically tested to provide unmatched comfort and support while reducing pressure on soft tissue.
Specifications
Crankset |
3 pc, Alloy Forged Arms |
Chainrings |
40T |
Bottom Bracket |
68mm, square taper, 124.5mm length |
Chain |
KMC X8 w/ Missing Link™, 8-speed |
Rear Derailleur |
MicroSHIFT Advent 8 Speed, W/O Clutch |
Cassette |
MicroSHIFT, 8-Speed, 12-42t |
Shift Levers |
MicroSHIFT, 8-speed |
Stem |
3D-forged alloy, 31.8mm, 7-degree rise |
Grips |
Slip-on, Closed End Grips |
Saddle |
Specialized Body Geometry Comfort Gel |
Handlebars |
Specialized Roll, 6061 alloy, Double butted, 15-degree backsweep, 136mm rise, 31.8mm |
SeatPost |
Spring suspension, alloy, 27.2mm, 2-bolt clamp |
Rims |
650b disc, double-wall alloy, pinned, 32h |
Rear Hub |
Alloy, 6-bolt disc, Shimano, 8/9-speed freehub, 135mm spacing, quick-release, 36h |
Front Hub |
Alloy, 6-bolt disc, loose ball bearing, quick-release, 32h |
Rear Tire |
Nimbus II Sport, 650b x 2.3" |
Front Tire |
Nimbus II Sport, 650b x 2.3" |
Spokes |
Stainless, 14g |
Inner Tubes |
Standard 48mm SV 27.5X1.75/2.4 |
Seat Binder |
Quick-release clamp, 31.8mm |
Frame |
Specialized A1 Premium Aluminum, Ground Control Positioning, formed tubes, post-mount disc, fender/rack mounts |
Pedals |
Specialized Body Geometry Fitness, platform, plastic |
Fork |
Steel formed tubes, post-mount disc, fender/rack mounts |
Rear Brake |
Tektro HD-T275, hydraulic disc, 160 mm rotor |
Front Brake |
Tektro HD-T275, hydraulic disc, 180 mm rotor |
Geometry
S | M | L | XL | |
---|---|---|---|---|
Crank Length | 165mm | 170mm | 175mm | 175mm |
Handlebar Width | 680mm | 680mm | 680mm | 680mm |
Stem Length | 70mm | 70mm | 70mm | 70mm |
Saddle Width | 200mm | 200mm | 200mm | 200mm |
Seatpost Length | 350mm | 350mm | 350mm | 350mm |
Stack | 583mm | 616mm | 644mm | 667mm |
Reach | 346mm | 352mm | 370mm | 392mm |
Head Tube Length | 155mm | 185mm | 215mm | 240mm |
Head Tube Angle | 68° | 69° | 69° | 69° |
BB Height | 285mm | 285mm | 285mm | 285mm |
BB Drop | 70mm | 70mm | 70mm | 70mm |
Trail | 84mm | 77mm | 77mm | 77mm |
Fork Length, Full | 420mm | 420mm | 420mm | 420mm |
Fork Rake/Offset | 55mm | 55mm | 55mm | 55mm |
Front Center | 617mm | 624mm | 653mm | 684mm |
Chainstay Length | 480mm | 480mm | 480mm | 480mm |
Wheelbase | 1088mm | 1095mm | 1124mm | 1155mm |
Top Tube Length, Horizontal | 594mm | 613mm | 643mm | 675mm |
Bike Standover Height | 801mm | 850mm | 881mm | 911mm |
Seat Tube Length | 375mm | 440mm | 480mm | 520mm |
Seat Tube Angle | 67° | 67° | 67° | 67° |
