Get a feel for the trail with this all-new aluminum hardtail made for aspiring singletrack riders. It features stable, fast-rolling 29-inch wheels so you can push the pace on climbs and let loose on the descents.

Built on a new lightweight ALUXX aluminum frame that features classic hardtail design plus the balanced riding characteristics of either larger diameter 29-inch wheels, Talon is a great choice for XC or light trail terrain. The frame geometry is specifically designed to adapt to its respective wheel size and a 100mm suspension fork) It’s a confident ride that’s perfect for ambitious riders who want to take their off-road skills to the next level.

Proven alloy performance

ALUXX aluminum frameset is hand-built in-house by the world leader in aluminum engineering.

Balance and stability

Frame geometry is designed to optimize the balance and roll-over capabilities of 29-inch wheels.

XC control

The suspension fork offers 100mm of smooth travel for added XC control.

Specifications

Sizes	S,M,L,XL
Colors	Trekking Green, Metallic Black
Frame	ALUXX-Grade Aluminum, disc
Fork	SR Suntour XCE 29 (100mm travel)
Shock	N/A
Handlebar	Giant Connect Trail, 31.8
Stem	Giant Sport
Seatpost	Giant Sport, 30.9
Saddle	Giant custom
Pedals	Platform
Shifters	Shimano SL-M315
Front Derailleur	Shimano M315
Rear Derailleur	Shimano Tourney
Brakes	Tektro TKD 172, mechanical
Brake Levers	RS360A
Cassette	Shimano MF-TZ500, 14x28
Chain	KMC Z7
Crankset	ProWheel forged, 22/36
Bottom Bracket	cartridge
Rims	Giant GX03V 29, alloy, double wall, 21mm inner width
Hubs	Giant Sport Tracker, 32h
Spokes	Stainless
Tires	Maxxis Ikon 29x2.2, wire bead

Geometry

	S (29")	M (27.5")	M (29")	L (29")	XL (29")
SEAT TUBE LENGTH (inch)	15.4	16.9	17.3	19.3	21.1
SEAT TUBE ANGLE	74.0°	74.0°	74.0°	74.0°	74.0°
TOP TUBE LENGTH (inch)	22.7	23.5	23.6	24.4	25.2
HEAD TUBE LENGTH (inch)	3.7	5.1	4.1	4.9	5.5
HEAD TUBE ANGLE	68.5°	67.5°	68.5°	68.5°	68.5°
FORK RAKE (inch)	2	1.7	2	2	2
TRAIL (inch)	3.7	4.1	3.7	3.7	3.7
WHEELBASE (inch)	44.3	44.8	45.3	46.1	46.9
CHAIN STAY LENGTH (inch)	17.9	17.3	17.9	17.9	17.9
BOTTOM BRACKET DROP (inch)	2.2	1.8	2.2	2.2	2.2
STACK (inch)	23.7	23.5	24.1	24.8	25.4
REACH (inch)	15.9	16.7	16.7	17.3	17.9
STAND OVER HEIGHT (inch)	28.8	29.4	30.2	31.7	33
HANDLEBAR WIDTH (inch)	30.7	30.7	30.7	30.7	30.7
STEM LENGTH (inch)	2	2.4	2.4	2.8	3.1
CRANK LENGTH (inch)	6.7	6.9	6.9	6.9	6.9
WHEEL SIZE	29"	27.5"	29"	29"	29"
