General Info
- Weight: 60.48 lbs
- Total Weight Limit: 330 lbs
- Ebike Class: Class 2 Ebike
- Water Resistance: Bike - IPX5 // Components - IPX6
- Range: Up to 75 Miles
- Safety Certifications: UL Safety Certified, UL 2849
- Battery Safety Certifications: Certified to UL 2271
- Rider Height: Size R: 5'0" - 5'9" | Size L: 5'9" - 6'3"
- Speed: Max 28 MPH
Cockpit
- Saddle: Aventon 250mm wide Saddle
- Seatpost: Aventon Seatpost, 30.9Ø, Length: 300 mm (Size R) / 350 mm (Size L)
- Seatpost Clamp: 34.9mm
- Handlebars: Aventon aluminum swept back handlebars. 31.8mm, 620mm, 38mm rise
- Stem: 60mm length, Adjustable rise, 31.8 handlebar clamp
- Grips: Aventon Lock on grips
- Headset: Sealed Bearing Headset
Frameset
- Frame: 6061 Aluminum, Gravity Cast Front Triangle
- Fork: Aventon Rigid Alloy
- Rear Spacing: 147mm
- Fork Spacing: 100mm
Wheelset
- Front Wheel: 27.5" Double Wall Aluminum rim, 36 13g spokes, 15x100mm Thru Axle, Schrader Valve
- Rear Wheel: 27.5" Double Wall Aluminum rim, 36 12g spokes, 750W Nutted Axle Hub Motor, Schrader Valve
- Tires: 27.5x2.1 33TPI
Brakes
- Front Brake: Tektro HD-E3120 hydraulic disc
- Rear Brake: Tektro HD-E3120 hydraulic disc
- Front Brake Rotor: 180mm 6 bolt
- Rear Brake Rotor: 180mm 6 bolt
- Additional: Regenerative Braking
Drivetrain
- Cassette: Shimano CS-HG200-8 8 speed Cassette, 12-32T
- Rear Derailleur: Shimano Altus RD-M310 8 Speed
- Shifter: Shimano 8 Speed Trigger SL-M315-8R
- Chain: 7/8 speed 122L
- Chainring: 48T
- Crankset: 3pc, 165mm crank arm
- Bottom Bracket: Square Tapered, Sealed, Double Sided Torque Sensor, 83mm x 158.5mm
- Pedals: 9/16" Composite Platform
Ebike System
- Motor: 36V, 750W Hub Drive
- Motor Torque: 80Nm (96Nm in Boost Mode)
- Motor Power: 750W, 1188 Watt Peak (1440 watt peak in boost mode)
- Display: Aventon A280
- Battery: Removable Internal Lithium-ion. 36V, 20Ah, 733Wh, LG 21700 cells
- Battery Weight: 8.7lbs
- Controller: 36V, 33A
- Throttle: Aventon LH Handlebar Mounted
- Sensors: Double Sided Bottom Bracket Torque Sensor
- Charger: 36V Output: 42V/ 4A
- Charging time: 5 hours (0% to 100%)
- Lights: Front and rear lights integrated
- ACU Over-The-Air Updates: Yes
- Smart Features: Regenerative Braking, Ride Tune, 4G/GPS, Unusual activity detection, E-lock, Hold Mode, Remote Notification, Apple Watch Connectivity, Keyless Battery, Cruise Control, Boost Mode, Sensor Switch
Please Note: Product images are for illustrative purposes only. Manufacturers occasionaly make updates to components, specifications, and finishes, meaning the actual bike you receive may vary slightly from the photos. However, any substituted parts will always be of like or better quality. If you have any questions about specific components, please don't hesitate to reach out to our team so we can get you the most up-to-date info on our current stock.
