Introducing the Trance X Advanced E+ 2 Electric Mountain Bike - the ultimate thrill-seeker's dream ride! With its advanced motor technology, plush suspension, and lightweight composite frame, this trailblazer blends power, performance, and flat-out fun to create an unforgettable riding experience.

Featuring a SyncDrive Pro motor with 85Nm of torque, this bad boy delivers powerful pedaling assistance even at low speeds. The 140mm of Maestro rear suspension travel and 150mm up front, along with a stiff Advanced-grade composite frame, ensure confident handling and control on even the roughest trails.

But that's not all - the Trance X Advanced E+ 2 is also adaptable to the terrain, thanks to its flip chip feature. You can fine-tune the handling for varying trail conditions and individual riding style, choosing between a low position for fast, aggressive terrain, or high for a more XC-oriented rider position.

And the icing on the cake? A clean cockpit design, with user-friendly controls integrated right into the top tube and handlebars. So what are you waiting for? Get ready to take your mountain biking adventures to the next level with the Trance X Advanced E+ 2!

Powerful and responsive

SyncDrive Pro motor with 85Nm of torque creates powerful pedaling assistance even at low speeds. Lightweight, stiff Advanced-grade composite frame with 140mm of Maestro rear suspension travel and 150mm up front delivers confident handling and control on rough trails.

Adaptable to the terrain

Flip chip feature lets you change the head tube and seat tube angles, along with the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style. You can choose the low position for fast, aggressive terrain, or high for a more XC-oriented rider position.

Clean cockpit

RideControl Go top tube integrated multi-function on/off button and RideControl Ergo 3 handlebar-mounted remote, which can be mounted on either grip, offer user-friendly controls and an uncluttered cockpit design.

RANGE

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

ENERGYPAK 800 / SYNCDRIVE PRO
Range

Extreme: 43 miles
Good: 86 miles
Ideal: 155 miles

Specifications

Motor	SyncDrive Pro, 85Nm, powered by Yamaha
Controller	RideControl GO integrated in TT, RideControl Ergo 3
Display	ANT+ cycle computer compatible
Battery	EnergyPak Smart 800, EnergyPak Plus range extender compatible
Sizes	S, M, L, XL
Colors	Gloss Carbon Smoke/ Matte Carbon Smoke
Frame	Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system
Fork	Fox 36 Float Performance, 150mm travel, 44mm offset, Grip 3-position Micro Adjust damper, Boost 110x15QR, e-optimized
Shock	Fox DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
Handlebar	Giant Contact 35 Trail, 35x780mm
Grips	Giant Tactal Pro-E, single lock-on
Stem	Giant Contact SL 35
Seatpost	Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
Saddle	Giant Romero, Neutral
Pedals	Flatpedal
Shifters	Shimano Deore SLX
Front Derailleur	MRP HD2 co-moulded chain guide
Rear Derailleur	Shimano Deore SLX, 12-speed, Shadow+
Brakes	Shimano SLX, BR-M7120, 4-piston, hydraulic disc, 203mm
Brake Levers	Shimano SLX, I-spec EV
Cassette	Shimano CS-M6100, 10-51T, 12-speed
Chain	KMC e.12 Sport, NP/NP, e-bike optimized
Crankset	Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S:160mm, M/L: 165mm, XL:170mm)
Bottom Bracket	n/a
Rims	Giant AM 29", Tubeless ready, 30mm inner width, e-bike optimized
Hubs	Shimano MT410, Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Spokes	Sapim E-Lite [R] Race [F], e-bike optimized
Tires	Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F]Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra [R]
Extras	Tubeless kit (liquid, valves, levers, manual, tool)Inner tube supplied
Lighting	Optional:- Giant Recon series e-bike lights available and direct connectable
Lock	Torx 25 Battery Lock with built-in Torque limiter
Weight	The most accurate way to determine any bike’s weight is to have your local Bicycle Warehouse dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Geometry

		S	M	L	XL
		LOW \| HIGH	LOW \| HIGH	LOW \| HIGH	LOW \| HIGH
A	SEAT TUBE LENGTH (inch)	15.7	16.7	17.7	18.7
B	SEAT TUBE ANGLE	77.2° \| 78.0°	76.0° \| 76.7°	76.0° \| 76.7°	76.0° \| 76.7°
C	TOP TUBE LENGTH (inch)	22.7 \| 22.6	23.9 \| 23.8	25.1 \| 25	26.3 \| 26.2
D	HEAD TUBE LENGTH (inch)	3.7	3.9	4.3	4.7
E	HEAD TUBE ANGLE	65.7° \| 66.5°	65.8° \| 66.5°	65.8° \| 66.5°	65.8° \| 66.5°
F	FORK RAKE (inch)	1.7	1.7	1.7	1.7
G	TRAIL (inch)	4.6 \| 4.8	4.6 \| 4.8	4.6 \| 4.8	4.6 \| 4.8
H	WHEELBASE (inch)	48 \| 48.1	48.8 \| 48.7	49.9 \| 50	51.2 \| 51.2
I	CHAIN STAY LENGTH (inch)	18.6 \| 18.6	18.6 \| 18.6	18.6 \| 18.6	18.6 \| 18.6
J	BOTTOM BRACKET DROP (inch)	1.2 \| 0.8	1.2 \| 0.8	1.2 \| 0.8	1.2 \| 0.8
K	STACK (inch)	23.9 \| 23.7	24.1 \| 23.8	24.4 \| 24.2	24.8 \| 24.6
L	REACH (inch)	17.3 \| 17.6	18 \| 18.2	19 \| 19.3	20.1 \| 20.4
M	STAND OVER HEIGHT (inch)	29.1 \| 29.4	28.6 \| 28.9	28.3 \| 28.6	28.1 \| 28.5
N	HANDLEBAR WIDTH (inch)	30.7	30.7	30.7	30.7
O	STEM LENGTH (inch)	1.6	1.6	2	2
P	CRANK LENGTH (inch)	6.3	6.5	6.5	6.7
Q	WHEEL SIZE	29"	29"	29"	29"
