| S0 / XXS | S1 / XS | S2 / S | S3 / M | S4 / L | S5 / XL | S6 / XXL |
| 4'9" - 5'2" | 4'11" - 5'3" | 5'2" - 5'8" | 5'5" - 5'11" | 5'8" - 6'2" | 5'10" - 6'4" | 6'2" - 6'8" |
Size Down for More Maneuverability, Size Up for More Stability

|
Frame |
FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel |
|
SWAT |
Increased-volume SWAT™ Door integration with 22oz SWAT™ Bladder |
|
Seat Binder |
Alloy, 38.6mm |
|
Rear Shock |
FOX FLOAT X Performance, Rx Trail Tune, EVOL Air sleeve, 2-position lever w/ LSR adjustment, S1:210x50mm, S2-S6:210x55mm |
|
Fork |
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1:150mm of travel, S2-S6:160mm of travel |
|
Stem |
Alloy Trail Stem, 35mm bar bore |
|
Handlebars |
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width |
|
Tape |
Specialized Trail Grips |
|
Saddle |
Bridge Comp, Hollow Cr-mo rails, 155/143mm |
|
SeatPost |
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm |
|
Front Brake |
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm |
|
Rear Brake |
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm |
|
Rear Derailleur |
SRAM GX Eagle, 12-speed |
|
Shift Levers |
SRAM GX, trigger, 12-speed |
|
Cassette |
Sram XG-1275, 12-speed, 10-52t |
|
Chain |
SRAM NX Eagle, 12-speed |
|
Crankset |
SRAM X1 6K, DUB, S1:165mm, S2-S5: 170mm, S6: 175mm |
|
Chainrings |
Alloy, 30T |
|
Bottom Bracket |
SRAM DUB, BSA 73mm, Threaded |
|
Rims |
Specialized 29, hookless alloy, 30mm inner width, tubeless ready |
|
Front Hub |
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h |
|
Rear Hub |
REAR HUB,BEAR PAWL BMB-00412O1C,SRAM XD STEEL FHB ,6 BOLT DISC,SEALED CARTRIDGE BEARING,28H,12MM AXLE,148MM SPACING |
|
Spokes |
DT Swiss Industry |
|
Front Tire |
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
|
Rear Tire |
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 29x2.3" |
|
Inner Tubes |
TUBES,STANDARD 48MM PV LOW LEAD 29x1.75/2.4, MAXXIS BRAND |
|
Pedals |
PEDAL, TEST RIDE PEDALS PROVIDED BY SPECIALIZED |
| S1 | S2 | S3 | S4 | S5 | S6 | |
|---|---|---|---|---|---|---|
| Crank Length | 165mm | 170mm | 170mm | 170mm | 170mm | 175mm |
| Seatpost Length | 100mm | 125mm | 150mm | 170mm | 170mm | 190mm |
| Handlebar Width | 800mm | 800mm | 800mm | 800mm | 800mm | 800mm |
| Stem Length | 40mm | 40mm | 50mm | 50mm | 50mm | 50mm |
| Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm | 143mm |
| Stack | 613mm | 617mm | 626mm | 635mm | 644mm | 654mm |
| Reach | 408mm | 428mm | 448mm | 475mm | 498mm | 528mm |
| Headtube Length | 95mm | 95mm | 105mm | 115mm | 125mm | 135mm |
| Headtube Angle | 64.5° | 64.5° | 64.5° | 64.5° | 64.5° | 64.5° |
| BB Height | 335mm | 340mm | 340mm | 340mm | 340mm | 340mm |
| BB Drop | 40mm | 35mm | 35mm | 35mm | 35mm | 35mm |
| Trail | 131mm | 131mm | 131mm | 131mm | 131mm | 131mm |
| Fork Length (full) | 561mm | 571mm | 571mm | 571mm | 571mm | 571mm |
| Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm | 44mm |
| Front Center | 732mm | 756mm | 780mm | 809mm | 838mm | 873mm |
| Chainstay Length | 438mm | 438mm | 438mm | 438mm | 448mm | 448mm |
| Wheelbase | 1167mm | 1191mm | 1216mm | 1247mm | 1285mm | 1319mm |
| Top-tube Length (horizontal) | 538mm | 564mm | 590mm | 623mm | 647mm | 679mm |
| Bike Standover Height | 733mm | 764mm | 763mm | 762mm | 767mm | 770mm |
| Seat Tube Length | 385mm | 385mm | 405mm | 425mm | 445mm | 465mm |
| Seat Tube Angle | 78° | 77.6° | 77.2° | 76.9° | 77° | 77° |
| Max Seatpost Insertion | 180mm | 180mm | 200mm | 220mm | 240mm | 260mm |
| Min Seatpost Insertion | 80mm | 80mm | 80mm | 80mm | 80mm | 80mm |
