Surly Grappler Bike - 27.5 Steel Frame

Surly Grappler Bike - 27.5 Steel Frame

Regular price $1,899.00
THIS BIKE SHIPS FREE!
Regular price $1,899.00 Sale price $1,899.00
Sale Sold out
Size
FREE $100 GIFT CARD WITH PURCHASE
Your Black Friday Bonus is sent when your bike ships.

Have questions about buying a bike?
Chat with a specialist ↗
Our Platinum Pro Assembly fee of only $79 will be added at checkout to cover the professional bike build and re-packaging by our certified teach team. Your new Surly bike comes 90% built, reassembly is quick and easy with our video guides.

In stock

SKU:04-002082

View full details

Experience the versatility and durability of this dedicated drop-bar trail bike, expertly crafted for confident handling on single track, double track, and a variety of rugged terrains.

Designed with mountain geometry tailored around a comfortable drop-bar hand position, it delivers a lively and responsive ride perfect for all-day dirt adventures and quick bikepacking excursions. Built around robust 27.5” wheels, this bike features front and rear thru-axles that provide exceptional stiffness and precise handling. Its frame accommodates internally geared hubs and single-speed setups, thanks to a proprietary horizontal-slotted dropout spacing that supports both 142mm and 148mm rear hubs. Constructed from 100% high-quality Chromoly steel, the frame and fork utilize proprietary double-butted tubing with a 1-1/8” headtube, ensuring a rigid, non-suspension corrected structure that balances strength and ride comfort. The frame is E.D. coated to enhance longevity and resist corrosion, making it a reliable companion for years to come. Additional thoughtful features include seatstay-mounted bottle bosses and multiple three-pack mounts located at the top and bottom of the down tube, enabling ample storage options for hydration and gear. Stealth dropper post routing is integrated for seamless upgrades. This bike offers generous tire clearance up to 27.5 x 2.8” with or without fenders, allowing for versatile tire choices to suit various trail conditions. Equipped with disc brakes for confident stopping power and a rigid steel fork that complements the frame’s durability, it stands out as a dependable touring bike ready to tackle diverse outdoor challenges.

Frameset

Frame: 100% Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated

Fork: Surly Dinner Fork, 100% Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated

Seatclamp: Surly Stainless 33.1

Drivetrain

Crankset: Samox BSA 2PCS Boost 32t

Bottom Bracket: Samox BSA

Front Derailleur: N/A

Rear Derailleur: microSHIFT M6205

Cassette / Cog: microSHIFT 11–48t

Chain: KMC X10 Black

Components

Grips / Bar Tape: Cork, Black

Handlebar: Salsa Cowchipper 31.8

Stem: Promax DA-296, 31.8mm

Headset: Cane Creek 40

Shifter: microSHIFT SB-M100A, AdventX Dual Control Levers

Brakes Calipers and Rotors: Tektro Mira MD-C400, Tektro 180/160

Saddle: WTB Volt 142

Seatpost: TransX YSP15 Dropper 360mm, 100mm travel

Wheels

Front Hub: Novatec 15x110mm, 32h

Rear Hub: Novatec 12x148mm, 32h

Rims: WTB ST i40 TCS

Tires: Teravail Ehline, 27.5 x 2.5", 60tpi

Tubes: Included and installed

Other

Pedals: Sold Separately

No technical specifications available.
Frame measurements (mm) XS SM MD LG XL
A. BB Drop 50 50 50 50 50
B. Chainstay Length 425 425 425 425 425
C. Fork Length - Axle to Crown 420 420 420 420 420
D. Fork Offset 50 50 50 50 50
E. Head Tube Angle (deg) 69.5 69.5 69.5 69.5 69.5
F. Headtube Length 160 180 200 220 240
G. Reach 381 405 420 444 458
H. Seat Tube Angle (deg) 73.0 73.0 73.0 73.0 73.0
I. Seat Tube Length - Center to Top 316 386 437.2 488 539
J. Stack 585 604 623 641 660
K. Standover 719 762 795 829 862
L. Top Tube Length (Effective) 560 590 610 640 660
M. Wheelbase 1057 1088 1109 1140 1162
Component measurements (mm)
Crank Arm Length 170 170 175 175 175
Handlebar Width 400 420 440 460 480
Stem Length 60 60 60 60 60
