Extra travel, extra fun. From rowdy enduro runs to backcountry missions on steep, chunky singletrack, this new composite 29er builds on the Trance X Advanced Pro 0 29er Mountain Bike platform with beefed up suspension and adjustable frame geometry.

This new member of the Trance family is designed with a longer travel suspension setup for added control on the most challenging trails. The full composite frame is engineered for 135mm of rear travel and 150mm up front. The Maestro rear suspension has a two-stage adjustable Advanced Forged Composite rocker arm with a trunnion-mount shock. The flip-chip equipped rocker arm lets you adjust frame geometry for your own riding style and terrain. To fine tune the ride, you can choose a steeper or slacker headtube angle (66.2 or 65.5 degrees) and seattube angle (77.9 or 77.2 degrees), which results in either a 30mm or 40mm bottom bracket drop. And it’s all built around 29-inch wheels for added stability on rugged terrain.

KEY PERFORMANCE FACTORS

29er confidence and control

Optimized Maestro suspension for 29-inch wheels with 135mm rear/ 150mm front travel to roll over rough terrain with balance and stability, giving you more momentum for technical climbs and the confidence to fly on fast, rugged singletrack descents. Added clearance for up to 2.5-inch tires.

Full Composite Construction

Mainframe and rear swingarm are engineered with proprietary material featuring high-performance carbon fiber and resin. Handcrafted monocoque construction makes it lightweight, stiff and compliant.

Adjustable frame geometry

Flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.5/77.2 head/seattube angle and 40mm BB drop) for faster, open terrain or high (66.2/77.9 head/seattube angle and 30mm drop) for slower, tighter singletrack.

Specifications

Sizes	S, M, L, XL
Colors	Carbon Smoke/Metallic Black/Chrome
Frame	Advanced-Grade Composite front and rear triangles, 135mm Maestro suspension, flip chip
Fork	Fox 36 Performance Elite, 150mm, GRIP2 damper, 15x110 Kabolt, 44mm offset, custom tuned for Giant
Shock	Fox Float DPX2 Performance, 185/55, custom tuned for Giant
Handlebar	Giant Contact SLR Trail, composite, 35
Stem	Giant Contact SL 35
Seatpost	Giant Contact Switch dropper with remote, 30.9
Saddle	Giant Romero SL, SST rails
Pedals	N/A
Shifters	SRAM GX Eagle
Front Derailleur	N/A
Rear Derailleur	SRAM GX Eagle
Brakes	SRAM G2 R hydraulic (F:200mm, R:180mm)
Brake Levers	SRAM G2 R
Cassette	SRAM XG-1275 Eagle, 12-speed, 10x52
Chain	SRAM NX Eagle
Crankset	Truvativ Descendent 6k Eagle, DUB Boost, 30t
Bottom Bracket	SRAM DUB, press fit
Rims	Giant TRX-2 29 WheelSystem, 30mm inner
Hubs	Giant TRX-2 29 WheelSystem, Boost
Spokes	Giant TRX-2 29 WheelSystem, DBL technology
Tires	[F] Maxxis Minion DHF, tubeless, 29x2.5, WT, 3C, MaxxTerra, EXO, TR [R] Maxxis Dissector, tubeless, 29x2.4, WT, 3C, MaxxTerra, EXO, TR
Extras	Tubeless prepared

Geometry

		S	M	L	XL
		LOW \| HIGH	LOW \| HIGH	LOW \| HIGH	LOW \| HIGH
A	SEAT TUBE LENGTH (inch)	16.9	16.9	18.3	19.5
B	SEAT TUBE ANGLE	77.2° \| 77.9°	77.2° \| 77.9°	77.2° \| 77.9°	77.2° \| 77.9°
C	TOP TUBE LENGTH (inch)	22.3 \| 22.2	23.5 \| 23.4	24.8 \| 24.7	25.8 \| 25.7
D	HEAD TUBE LENGTH (inch)	3.7	3.9	4.3	4.7
E	HEAD TUBE ANGLE	65.5° \| 66.2°	65.5° \| 66.2°	65.5° \| 66.2°	65.5° \| 66.2°
F	FORK RAKE (inch)	1.7	1.7	1.7	1.7
G	TRAIL (inch)	4.9 \| 4.7	4.9 \| 4.7	4.9 \| 4.7	4.9 \| 4.7
H	WHEELBASE (inch)	46.2 \| 46.1	47.4 \| 47.4	48.8 \| 48.7	49.9 \| 49.8
I	CHAIN STAY LENGTH (inch)	17.2 \| 17.1	17.2 \| 17.1	17.2 \| 17.1	17.2 \| 17.1
J	BOTTOM BRACKET DROP (inch)	1.6 \| 1.2	1.6 \| 1.2	1.6 \| 1.2	1.6 \| 1.2
K	STACK (inch)	24.3 \| 24.1	24.4 \| 24.2	24.8 \| 24.6	25.2 \| 25
L	REACH (inch)	16.8 \| 17.1	18 \| 18.3	19.1 \| 19.4	20.1 \| 20.4
M	STAND OVER HEIGHT (inch)	28.7 \| 29.1	28.7 \| 29	29.6 \| 30	29.9 \| 30.3
N	HANDLEBAR WIDTH (inch)	31.5	31.5	31.5	31.5
O	STEM LENGTH (inch)	1.6	1.6	2	2
P	CRANK LENGTH (inch)	6.5	6.7	6.7	6.7
Q	WHEEL SIZE	29"	29"	29"	29"
