Introducing the Specialized Demo Race Downhill Full Suspension Mountain Bike - a speed demon with a twist! This bike is all about pushing the boundaries and finding the perfect balance between traction and maneuverability. AÂ new frame design lets you enjoy the best of both worlds - a 29-inch front wheel for smashing obstacles and a 27.5-inch rear wheel for nimble handling. This combination has been put through the paces by none other than the World Champ himself, Loic Bruni, and finally got the green light from the UCI last year. But hey, rules were meant to be broken, right? Because this bad boy still managed to bag the Downhill World Championship and overall World Cup titles in its very first season!
 So, if you're ready to blaze through tough trails with a grin from ear to ear, the Specialized Demo Race is the ride for you. Get ready to channel your inner Loic Bruni and experience the thrill of conquering any challenge that comes your way! Speed, style, and a little touch of rebel attitude - that's what the Demo Race is all about!
Features:
- The Demo Race M5 alloy frame is fully optimized to take advantage of the traction benefits of a 29-inch front wheel and the increased manueverability of a 27.5-inch rear wheel while maintaiining the ability to change your rear wheel size to suit different terrain and riding styles with an adjustable rear end that ensures chainstay length and bottom-bracket height stay dialed no matter the hoop size.
- The Ohlins TTX 22 M coil shock is designed to handle the most challenging World Cup Downhill tracks, offering external low speed compression and rebound adjustment while the Trunnion mount offers extra bushing overlap for increased durability.
- With superb small bump tracking and the ability to soak up landings from even the heftiest drop-off, the Ohlins DH38 m.1 fork’s 200-millimeters of travel will give you smoother, faster, and more confident feeling runs than anything you’ve ridden before.
Specifications
Frame |
M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel |
Seat Binder |
Alloy, 34.9mm |
Rear Shock |
Ohlins TTX 22 M Coil, external rebound adjust, external high and low speed compression adjustment, Trunnion mount, 225x75 |
Fork |
Ohlins DH38 M.1 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 20x110mm, 58mm offset, 200mm of travel |
Stem |
Descendant 35mm Direct Mount Stem, 50mm length |
Handlebars |
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm |
Grips |
Deity, Knuckleduster, Black |
Saddle |
Body Geometry Henge DH, hollow titanium rails, 130mm |
SeatPost |
Thomson, alloy, straight, 12-degree clamp |
Front Brake |
Magura MT7, 4-piston caliper, hydraulic disc, 200mm |
Rear Brake |
Magura MT7, 4-piston caliper, hydraulic disc, 200mm |
Rear Derailleur |
SRAM X01 DH, 7-speed, trigger |
Shift Levers |
SRAM X01 DH, trigger, 7-speed |
Cassette |
SRAM X01 DH, 7-speed, 10-24t |
Chain |
Sram PC1130 w/ Powerlink, 11-speed |
Crankset |
SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm |
Chainrings |
34T |
Bottom Bracket |
SRAM DUB, 83mm |
Rims |
Roval 29" Alloy DH, 28mm internal width, 28h, tubeless ready |
Front Hub |
Alloy, sealed cartridge bearings, 20x110mm, 28h |
Rear Hub |
DT Swiss 350, SRAM XD freehub, 6-bolt disc, high-low flange, sealed cartridge bearings, 12x148mm spacing, 28h |
Spokes |
DT Swiss Competition, stainless steel, 14g |
Front Tire |
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
Rear Tire |
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 27.5x2.3" |
Inner Tubes |
Standard, Presta Valve |
Geometry
S2 | S3 | S4 | |
---|---|---|---|
Crank Length | 165mm | 165mm | 165mm |
Handlebar Width | 800mm | 800mm | 800mm |
Stem Length | 50mm | 50mm | 50mm |
Saddle Width | 130mm | 130mm | 130mm |
Seatpost Length | 367mm | 367mm | 367mm |
Stack | 632mm | 632mm | 632mm |
Stack (29 mid) | 629mm | 629mm | 629mm |
Stack (27.5 mid) | 635mm | 635mm | 635mm |
Reach | 426mm | 446mm | 466mm |
Reach (29 mid) | 430mm | 450mm | 470mm |
Reach (27.5 mid) | 423mm | 443mm | 463mm |
Head-Tube Length | 105mm | 105mm | 105mm |
Head-Tube Angle | 62.8° | 62.8° | 62.8° |
Head-Tube Angle (29 mid) | 63.2° | 63.2° | 63.2° |
Head-Tube Angle (27.5 mid) | 62.5° | 62.5° | 62.5° |
B-B Height | 350mm | 350mm | 350mm |
B-B Height (29 mid) | 355mm | 355mm | 355mm |
B-B Height (27.5 mid) | 345mm | 345mm | 345mm |
B-B Drop | 25mm | 25mm | 25mm |
Trail | 130mm | 130mm | 130mm |
Trail (29 mid) | 127mm | 127mm | 127mm |
Trail (27.5 mid) | 132mm | 132mm | 132mm |
Fork Rake/Offset | 56mm | 56mm | 56mm |
Front-Center | 801mm | 821mm | 841mm |
Front-Center (29 mid) | 801mm | 821mm | 841mm |
Front-Center (27.5 mid) | 801mm | 821mm | 841mm |
Chain-Stay Length (29) | 448mm | 448mm | 448mm |
Chain-Stay Length (27.5) | 438mm | 438mm | 438mm |
Chain-Stay Length (mid) | 443mm | 443mm | 443mm |
Wheelbase (27.5) | 1239mm | 1259mm | 1279mm |
Wheelbase (29) | 1249mm | 1269mm | 1289mm |
Wheelbase (mid) | 1244mm | 1264mm | 1284mm |
Seat-Tube Length | 394mm | 420mm | 420mm |
Seat-Tube Angle | 78.2° | 76.8° | 76.8° |
Seat-Tube Angle (29 mid) | 78.5° | 77.1° | 77.1° |
Seat-Tube Angle (27.5 mid) | 77.8° | 76.4° | 76.4° |
