The Epic Evo Full Suspension 29" Mountain Bike – a beast of a bike that knows how to have a blast on the trails! Remember the good old days when cross country biking was all about the adventure, not just racing to the finish line? Well, the Epic EVO remembers too!
This bike may be up for some number plate action, but it's not afraid to embrace the joy of exploration either. With a perfect blend of pedaling efficiency and trail-conquering prowess, you'll be flying towards the next ridgeline or discovering new trails with a grin from ear to ear.
Don't be fooled by its seemingly modest 20-millimeter increase in front suspension and 10-millimeter at the back; this upgrade will have you shouting 'Whoa!' the moment you hit the singletrack. The folks behind the Epic EVO have put in some serious overtime to ensure an exhilarating ride that'll leave you craving more.
The bike's engineering prowess keeps the efficiency of its Epic sibling while unlocking the full potential of its suspension with new kinematics. So you can make the most out of every inch of travel, all while enjoying improved pedaling efficiency. It's like having the best of both worlds!
The Epic EVO proudly boasts the most capable version of Progressive XC Geometry ever seen on an Epic. Plus, with a nifty flip chip-equipped rear end, you can fine-tune the headtube angle and bottom bracket height to suit your riding style and trail preference. Talk about adaptability!
Crafted from flyweight FACT 11m carbon, this bike is a true speed demon. Outfitted with top-notch SRAM components and RockShox suspension, it's a tailor-made package that'll make those miles disappear faster than you can say "epic adventure."
So, hop on the Epic EVO and get ready for the ride of your life – it's a bike that embraces fun, adventure, and the thrill of the trail like no other. Are you up for the challenge? Get ready to unleash your inner mountain biking hero!
Features:
- Flip It To Rip It: Tune the ride of the Epic EVO’s FACT 11m carbon frame to match your preferred handling characteristics with flip-chip simplicity that allows riders to reduce the EVO’s headtube angle by half a degree while lowering bottom bracket height by 10 millimeters.
- The Reba RL doles out travel with a steady hand courtesy of RockShox's Motion Control damper, while SoloAir adjustability makes dialing in suspension performance a breeze.
- SRAM’s NX Eagle drivetrain is the benchmark for affordable high performance, delivering crisp shifting and a massive 450% gear range.
Specifications
Frame |
FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineeredâ„¢, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel |
Seat Binder |
SEAT COLLAR, KCNC, SPL-SC02-349-02, EXTRUDED, 7075-T73, 34.9MM, 10B21, BLACK ZINC BOLT, BOLT CLAMP TYPE |
Rear Shock |
RockShox Deluxe Select+, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm |
Fork |
RockShox Reba RL, Motion Control damper, Solo Air, 42mm offset, 15x110mm thru-axle, 120mm of travel |
Stem |
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise |
Handlebars |
Specialized Alloy, 20mm rise, 31.8mm, 760mm wide |
Tape |
Specialized Trail Grips |
Saddle |
Body Geometry Power Sport, steel rails |
SeatPost |
TranzX Dropper, 30.9mm, XS-SM: 100mm, M: 125mm, L-XL: 150mm |
Front Brake |
SRAM Level T hydraulic disc, 2-Piston Caliper |
Rear Brake |
SRAM Level T hydraulic disc, 2-Piston Caliper |
Rear Derailleur |
SRAM NX Eagle, 12-speed |
Shift Levers |
SRAM NX Eagle, trigger, 12-speed |
Cassette |
SRAM NX Eagle, 12-speed, 11-50t |
Chain |
SRAM SX Eagle, 12-speed |
Crankset |
SRAM X1000 Eagle, DUB, 170/175mm 32T |
Chainrings |
32T |
Bottom Bracket |
SRAM DUB, BSA 73mm, Threaded |
Rims |
Specialized Alloy, Tubeless Ready, 29mm internal width, 28h |
Front Hub |
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h |
Rear Hub |
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h |
Front Tire |
Specialized Ground Control, Control Casing, T5 Compound, 29x2.35 |
Rear Tire |
Specialized Ground Control, Control Casing, T5 Compound, 29x2.35 |
Inner Tubes |
TUBES,STANDARD 48MM PV LOW LEAD 29x1.75/2.4, MAXXIS BRAND |
Geometry
XSmall | Small | Medium | Large | XLarge | |
---|---|---|---|---|---|
Crank Length | 165mm | 170mm | 175mm | 175mm | 175mm |
Stem Length | 60mm | 60mm | 60mm | 60mm | 60mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm | 760mm |
Seatpost Length | 100mm | 125mm | 125mm | 150mm | 150mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
Stack | 603mm | 593mm | 597mm | 611mm | 629mm |
Reach | 380mm | 406mm | 436mm | 460mm | 485mm |
Head Tube Length | 95mm | 95mm | 100mm | 115mm | 135mm |
Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° |
BB Height | 326mm | 336mm | 336mm | 336mm | 336mm |
BB Drop | 46mm | 36mm | 36mm | 36mm | 36mm |
Trail | 114mm | 114mm | 114mm | 114mm | 114mm |
Fork Length, Full | 530mm | 530mm | 530mm | 530mm | 530mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm |
Front Center | 672mm | 697mm | 729mm | 759mm | 792mm |
Chainstay Length | 438mm | 438mm | 438mm | 438mm | 438mm |
Wheelbase | 1106mm | 1132mm | 1164mm | 1194mm | 1227mm |
Bike Standover Height | 760mm | 779mm | 781mm | 793mm | 804mm |
Seat Tube Length | 375mm | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 75.5° | 74.8° | 74.5° | 74.5° | 74.5° |
Top Tube Length, Horizontal | 536mm | 567mm | 602mm | 629mm | 659mm |
