The Epic Evo Comp Full Suspension 29" Mountain Bike 2023: the two-wheeled embodiment of pure joy! This bike is a master of contradictions, effortlessly combining lightweight with stiffness, capability with efficiency, and FUN with focus.
Don't let the seemingly small 20-millimeter increase in front suspension and 10-millimeter at the back fool you – it's the magic touch that will leave you saying 'Whoa!' as you hit the thrilling singletrack. The engineering wizards have worked their magic to maintain the Epic's legendary efficiency while enhancing the suspension kinematics. The result? The Rx XC Tune customized suspension system that lets you squeeze every inch of travel, with extra anti-squat characteristics for ultimate pedaling prowess.
This bike knows how to be ahead of the game! With the most capable Progressive XC Geometry ever seen on an Epic, it's a trail-blazing champion. But wait, there's more! Thanks to the innovative flip chip-equipped rear end, you can customize the headtube angle and bottom bracket height like a boss, giving you full control over the Epic EVO's handling.
In the pursuit of perfection, the Epic EVO Comp has assembled a stellar team. Four-piston SRAM G2 RS brakes bring the power, the X-Fusion Manic dropper adds that extra cool factor, and the RockShox SID Select fork ensures a smooth ride over any terrain.
Ready to embark on epic adventures? Say hello to the Epic Evo Comp, your trusty sidekick in the pursuit of two-wheeled greatness. Get ready to unleash the fun, tackle the trails, and own the mountains like never before!
Features:
- Flip It To Rip It: Tune the ride of the Epic EVO’s FACT 11m carbon frame to match your preferred handling characteristics with flip-chip simplicity that allows riders to reduce the EVO’s headtube angle by half a degree while lowering bottom bracket height by 10 millimeters.
- X-Fusion's Manic dropper post offers infinitely adjustable travel via it's slick shifter-stye remote lever for hassle-free operation when things get dicey.
- 4-piston calipers on an XC bike? What a wonderful time to be alive—SRAM's 4-piston G2 RS calipers offer plenty of smooth, controllable power to keep the EVO's newfound speed in check.
- Tubeless-ready rims feature a modern 30-millimeter internal width, allowing tires to achieve their ideal profile and footprint for optimal traction.
Specifications
Chainrings |
32T |
Bottom Bracket |
SRAM DUB, BSA 73mm, Threaded |
Shift Levers |
SRAM GX, trigger, 12-speed |
Rear Derailleur |
SRAM GX Eagle, 12-speed |
Chain |
SRAM NX Eagle, 12-speed |
Cassette |
Sram XG-1275, 12-speed, 10-52t |
Crankset |
SRAM, X1 Alloy Eagle, 12-speed |
Stem |
Alloy Stem, 35mm clamp, 60mm |
Saddle |
Body Geometry Power Sport, steel rails |
Handlebars |
Specialized Alloy, 20mm rise, 35mm, 760mm wide |
Tape |
Specialized Trail Grips |
SeatPost |
X-Fusion Manic, 30.9, 125/150 Travel, 0mm offset |
Rear Hub |
Specialized alloy, sealed cartridge bearings, 6-bolt, 148mmx12mm thru-axle, 28h |
Spokes |
DT Swiss Industry |
Rims |
Specialized 29, 27mm inner width, 28h, tubeless ready |
Front Tire |
Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35 |
Rear Tire |
Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35 |
Front Hub |
Specialized alloy, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 28h |
Inner Tubes |
Standard, Presta valve |
Frame |
FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineeredâ„¢, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel |
Seat Binder |
Specialized Alloy, 34.9mm |
Fork |
Rockshox SID Select, Charger RL Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel |
Rear Shock |
RockShox DELUXE Select+, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm |
Front Brake |
SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor |
Rear Brake |
SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor |
SWAT |
SWAT EMT Cage-Mount Tool |
Geometry
Small | Medium | Large | XLarge | |
---|---|---|---|---|
Crank Length | 170mm | 175mm | 175mm | 175mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm |
Stem Length | 60mm | 60mm | 60mm | 60mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 125mm | 125mm | 150mm | 150mm |
Stack | 593mm | 597mm | 611mm | 629mm |
Reach | 406mm | 436mm | 460mm | 485mm |
Head Tube Length | 95mm | 100mm | 115mm | 135mm |
Head Tube Angle | 66.5° | 66.5° | 66.5° | 66.5° |
BB Height | 336mm | 336mm | 336mm | 336mm |
BB Drop | 36mm | 36mm | 36mm | 36mm |
Trail | 114mm | 114mm | 114mm | 114mm |
Fork Length, Full | 530mm | 530mm | 530mm | 530mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Front Center | 697mm | 729mm | 759mm | 792mm |
Chainstay Length | 438mm | 438mm | 438mm | 438mm |
Wheelbase | 1132mm | 1164mm | 1194mm | 1227mm |
Bike Standover Height | 779mm | 781mm | 793mm | 804mm |
Seat Tube Length | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 74.8° | 74.5° | 74.5° | 74.5° |
Top Tube Length, Horizontal | 567mm | 602mm | 629mm | 659mm |
